Calculating Stair width / Placement


-Engress / Considering 185 area
185 / 2 * 0.3 = 27.75 Width
      Stair 44 + 44 + 12 = 100 Width


- Dont concern about not seeing to you the mass floor because of default setting Solution : Massing&Site > Show Mass by view Setting On


- Cut with each of mass
- In Same mass, if you add another mass, you don't have to click the 'Cut' order to cut the new one


- Multistory Top Level (In Property dialog box) : This will make the stair alignment according to the level
